Design Patterns for Agentic Workloads: A 2026 Field Guide

Introduction

Every team building with LLMs eventually hits the same wall. The demo agent that researched, coded, and filed tickets on Friday afternoon burns through your token budget on Monday, spins on a malformed tool response, or returns a confident answer built on a tool call that silently failed. The model didn’t get worse. The system around it was never designed for a component that is probabilistic, expensive, and occasionally wrong.

The good news is that the field has converged on a small vocabulary of composable patterns. SitePoint’s 2026 guide makes the case that fluency in a handful of patterns matters more than mastery of any single framework, and the sources reviewed for this article, from Anthropic’s engineering posts to independent production write-ups, describe largely the same six shapes. This guide walks through them with framework-free Python (exercised against a scripted stand-in model), then covers the cross-cutting layer that makes them production-safe: budgets, typed tool errors, context management, and the 2026 interop stack of MCP and A2A.

We focus on patterns and operational design, not on any one SDK. If you can call an LLM API and parse JSON, you can build everything below.

Workflows, Agents, and the Augmented LLM

Anthropic draws the most useful line in this space. Workflows are systems where LLMs and tools are orchestrated through predefined code paths. Agents are systems where the LLM dynamically directs its own process and tool usage. Both are built on the same primitive, the augmented LLM: a model connected to retrieval, tools, and memory. Anthropic’s post carries a note that much of the surrounding tooling has changed since its December 2024 publication, but the pattern vocabulary it introduced is still the baseline that most of the sources I reviewed build on.

In practice the line blurs. One production write-up observes that most real systems sit in between: a router picks one of a few prebuilt workflows, or an orchestrator hands a narrow task to a tightly constrained agent. Fully free-roaming agents remain rare for good reasons: cost, latency, and compounding errors.

That advice becomes a decision procedure. Read the chart top-down and stop at the first exit that works. Many applications never get past the first box, because a single well-prompted call with retrieval and good examples is enough.

The Six Patterns at a Glance

Each pattern buys something and charges something. Knowing the bill up front is most of the design work.

The last row deserves a picture, because every other pattern is a constrained version of it. An agent is an LLM using tools in a loop, grounded by what the environment returns at each step.

The loop terminates in one of two ways: the model decides it’s finished, or your code decides it’s finished. Anthropic’s guidance is to include stopping conditions such as a maximum iteration count. That second exit is the one this article keeps returning to.

Practical Implementation

We’ll build the patterns on a deliberately tiny foundation. Frameworks can make these patterns faster to assemble, but Anthropic warns that their abstractions can obscure the underlying prompts and responses and make debugging harder, and suggests starting with direct API calls. So here an “LLM” is just an async function.

Foundation: the LLM type, a shared budget, and a live adapter

# agentic_patterns.py — Python 3.11+, standard library only (adapter needs `anthropic`)
from __future__ import annotations

import asyncio
import json
import time
from dataclasses import dataclass, field
from typing import Awaitable, Callable

# An "LLM" is just an async function: (system_prompt, user_prompt) -> text.
LLM = Callable[[str, str], Awaitable[str]]


class BudgetExceeded(RuntimeError):
    pass


@dataclass
class Budget:
    """One budget shared by every pattern in a run."""
    max_calls: int = 25
    max_seconds: float = 120.0
    calls: int = 0
    started: float = field(default_factory=time.monotonic)

    def charge(self) -> None:
        self.calls += 1
        if self.calls > self.max_calls:
            raise BudgetExceeded(f"call limit {self.max_calls} exceeded")
        if time.monotonic() - self.started > self.max_seconds:
            raise BudgetExceeded(f"time limit {self.max_seconds}s exceeded")


def budgeted(llm: LLM, budget: Budget) -> LLM:
    async def call(system: str, user: str) -> str:
        budget.charge()
        return await llm(system, user)
    return call


# Live adapter (not used by the tests). Pass whichever model ID you run in production.
def anthropic_llm(model: str, max_tokens: int = 1024) -> LLM:
    from anthropic import AsyncAnthropic
    client = AsyncAnthropic()  # reads ANTHROPIC_API_KEY from the environment

    async def call(system: str, user: str) -> str:
        resp = await client.messages.create(
            model=model, max_tokens=max_tokens, system=system,
            messages=[{"role": "user", "content": user}],
        )
        return "".join(b.text for b in resp.content if b.type == "text")
    return call

Chaining and routing

Chaining trades latency for accuracy by making each call an easier task, and the gate between calls is plain code. Routing keeps one input type’s prompt from degrading another’s, and it should always have a safe default for labels the classifier invents.

async def chain(llm: LLM, topic: str) -> str:
    outline = await llm("Write a 5-bullet outline. One bullet per line.", topic)
    if len([l for l in outline.splitlines() if l.strip()]) != 5:  # the gate
        raise ValueError("outline gate failed: expected exactly 5 bullets")
    return await llm("Write a short article that follows this outline.", outline)


Handler = Callable[[str], Awaitable[str]]


async def route(llm: LLM, ticket: str, handlers: dict[str, Handler]) -> str:
    label = (await llm(
        f"Classify the ticket as one of: {', '.join(handlers)}. Reply with one word.",
        ticket,
    )).strip().lower()
    handler = handlers.get(label, handlers["other"])  # unknown label -> safe default
    return await handler(ticket)

Parallelization: sectioning and voting

Sectioning runs independent subtasks side by side. Voting runs the same check several times and thresholds the result. Anthropic notes that splitting guardrail screening into its own call tends to beat asking one call to both answer and police itself.

async def vote(llm: LLM, code: str, n: int = 3, threshold: int = 2) -> bool:
    system = "Review the code. Reply VULNERABLE or SAFE as the first word."
    verdicts = await asyncio.gather(*(llm(system, code) for _ in range(n)))
    flagged = sum(v.strip().upper().startswith("VULNERABLE") for v in verdicts)
    return flagged >= threshold

Orchestrator-workers

Structurally this resembles parallelization, but the subtasks aren’t predefined: the orchestrator decides them per input. That flexibility is also its weakness, so the code below validates the plan, caps the fan-out, and tolerates worker failure. One practitioner write-up describes orchestrators that produce a 14-step plan when three steps would do, and Anthropic’s research team reported that vague delegation led to duplicated work, which they fixed with explicit objectives and explicit boundaries per subtask. The prompt below bakes both lessons in.

Worker = Callable[[dict], Awaitable[str]]
MAX_SUBTASKS = 5


async def orchestrate(llm: LLM, task: str, workers: dict[str, Worker]) -> str:
    plan_system = (
        "Break the task into at most 5 independent subtasks. Return ONLY a JSON list of "
        '{"worker": <one of: ' + ", ".join(workers) + '>, "objective": str, "boundaries": str}. '
        "Boundaries must say what this subtask must NOT cover."
    )
    plan = json.loads(await llm(plan_system, task))
    plan = [s for s in plan if s.get("worker") in workers][:MAX_SUBTASKS]  # validate + cap
    if not plan:
        raise ValueError("orchestrator produced no valid subtasks")
    results = await asyncio.gather(
        *(workers[s["worker"]](s) for s in plan), return_exceptions=True
    )
    ok = [r for r in results if not isinstance(r, Exception)]
    failed = len(results) - len(ok)
    note = f"\n(NOTE: {failed} subtask(s) failed; say so in the answer.)" if failed else ""
    return await llm("Synthesize these worker results into one answer.", json.dumps(ok) + note)

Evaluator-optimizer

This pattern fits when you have clear criteria and feedback demonstrably improves the output. Two practices from production write-ups matter: give the evaluator its own prompt with binary, checkable criteria rather than a vague rubric, and have it return structured pass/fail results instead of free text.

async def refine(llm: LLM, task: str, criteria: list[str], max_rounds: int = 3) -> str:
    eval_system = (
        "You are a strict reviewer. For each criterion answer true/false. Return ONLY JSON: "
        '{"checks": {<criterion>: bool}, "feedback": "specific fixes for each false check"}'
    )
    draft = await llm("Write the best possible answer.", task)
    for _ in range(max_rounds):
        verdict = json.loads(await llm(
            eval_system, "Criteria:\n- " + "\n- ".join(criteria) + f"\n\nDraft:\n{draft}"))
        if all(verdict["checks"].values()):
            return draft
        draft = await llm("Revise the draft using the feedback.",
                          f"{draft}\n\nFeedback:\n{verdict['feedback']}")
    return draft  # best effort once the round budget is spent

The agent loop, with a leash

Three details separate this from a tutorial loop. Tools return a typed result, so failures can’t masquerade as empty successes. Tool output is truncated before it re-enters the context. And a circuit breaker catches the model repeating an identical call.

@dataclass
class ToolResult:
    ok: bool
    content: str


Tool = Callable[..., Awaitable[str]]


async def run_tool(tools: dict[str, Tool], name: str, args: dict, timeout: float = 10.0) -> ToolResult:
    if name not in tools:
        return ToolResult(False, f"unknown tool '{name}'. Available: {', '.join(tools)}")
    try:
        out = await asyncio.wait_for(tools[name](**args), timeout)
        return ToolResult(True, out[:2000])  # cap what re-enters the context
    except asyncio.TimeoutError:
        return ToolResult(False, f"{name} timed out after {timeout}s")
    except Exception as exc:  # explicit error instead of a silent empty result
        return ToolResult(False, f"{name} failed: {type(exc).__name__}: {exc}")


AGENT_SYSTEM = (
    'Reply ONLY with JSON. To use a tool: {"tool": str, "args": object}. '
    'To finish: {"final": str}. Never repeat an identical call.'
)


async def agent(llm: LLM, task: str, tools: dict[str, Tool], max_steps: int = 8) -> str:
    transcript = [f"TASK: {task}"]
    last_call = None
    for _ in range(max_steps):
        reply = json.loads(await llm(AGENT_SYSTEM, "\n".join(transcript)))
        if "final" in reply:
            return reply["final"]
        call = (reply["tool"], json.dumps(reply.get("args", {}), sort_keys=True))
        if call == last_call:  # circuit breaker on identical consecutive calls
            transcript.append("ERROR: identical call repeated. Change approach or finish.")
            continue
        last_call = call
        result = await run_tool(tools, reply["tool"], reply.get("args", {}))
        transcript.append(f"TOOL {reply['tool']} -> {'OK' if result.ok else 'ERROR'}: {result.content}")
    raise BudgetExceeded(f"agent used all {max_steps} steps without finishing")

Here is what the loop looks like against a scripted model that first asks for a log file that doesn’t exist, repeats itself, then recovers. This is the context the model sees on its final turn:

TASK: Why are we seeing 500s?
TOOL read_log -> ERROR: read_log failed: FileNotFoundError: api.log
ERROR: identical call repeated. Change approach or finish.
TOOL read_log -> OK: 12:01 ERROR db pool exhausted (max=10)

ANSWER: 500s come from DB pool exhaustion (max=10) at 12:01. | calls used: 4

What Autonomy Costs

Agentic designs spend tokens to buy capability, and Anthropic’s published numbers make the trade explicit. In its data, agents use about four times the tokens of a chat interaction and multi-agent systems about fifteen times. Its analysis suggests that a large share of multi-agent gains comes simply from spending enough tokens on the problem, which is why the payoff concentrates in breadth-first work with independent threads. Anthropic also notes that most coding tasks have fewer parallelizable pieces than research does.

Treat the 90.2% as a data point about one system on one internal benchmark, not a promise. The durable lesson is the shape of the trade: multi-agent pays off only when the task decomposes into independent parallel threads and the outcome is worth the spend.

The Cross-Cutting Layer

The six patterns are the skeleton. These four disciplines decide whether it stands up under load.

Context is a budget too. Every turn appends to the context window, and accumulated tool output can push the model past the point where it follows its own instructions. A 2025 context-rot report covering eighteen models found performance generally degrades as input grows. Four moves help: compact old turns or stale tool results once a threshold, tuned from real traces, is crossed; isolate work in subagents with their own windows that return distilled summaries; cap tool output (our run_tool truncates at 2,000 characters); and keep the tool manifest small. Every registered tool’s schema is injected on every call, so a sprawling toolset inflates cost and invites wrong-tool selection. Namespaced routing keeps each call’s manifest short.

Tools are an interface you design. Anthropic urges investing in the agent-computer interface as seriously as you would a human one: write tool descriptions like docstrings for a junior engineer, include edge cases and boundaries from similar tools, and poka-yoke the arguments so mistakes are hard to make. Its SWE-bench agent reportedly took more optimization effort on tools than on the prompt, and one fix was requiring absolute file paths after the agent kept stumbling on relative ones.

Assume misfires and shrink the blast radius. A narrower tool signature helps, but a model determined to act destructively will find the narrowest destructive tool it has. Default workers to read-only, scope credentials per worker, and require human approval for irreversible actions. Anthropic’s agent guidance also calls for pausing at checkpoints or blockers.

Observe at the step level. Model-layer metrics miss agent failures. Track tool calls per task (average and p95), steps per run, context tokens per turn, and cost per run, and alert on spikes. Anthropic reported that standard logging wasn’t enough for its multi-agent system and built custom monitoring of agent decisions.

Interop in 2026: MCP and A2A

Two protocols now cover the seams between systems. MCP moved to the Linux Foundation’s Agentic AI Foundation in December 2025, and A2A reached version 1.0 in 2026. They answer different questions.

Common Pitfalls and Troubleshooting

Conclusion

Agentic workloads reward restraint. Start with one good call, add a workflow pattern only where your evals show a gap, and let a model steer only the slice of the problem you can’t script. Whatever you build, wrap it in the same operational discipline: one shared budget, typed tool errors, bounded context, step-level traces, and approval gates for anything irreversible. Then use MCP and A2A for the seams rather than bespoke glue.

A rollout order that follows this logic:
